24pcs Ø5 AHD Metal Dome Camera
Description:
The KH-W202E2, one of our most popular Infrared Dome Security Cameras. With 1080p of high resolution and over 90 feet of night vision, our AHD Infrared Dome is sure to provide you with crisp and clear high resolution video.
The KH-W202E2 is versatile. It can be used both indoor and outdoor. It has a standard wide angle lens making it perfect to cover a wide area outside your home, a room or any area you wish to cover.
◆20-25M IR night vision
◆24pcs Ø5mm IR LEDs
◆3.6mm Fixed Wide Angle Lens, 6mm/8mm Optional
◆Color to B/W
◆3-Axis bracket
◆Black/White Case
|
Model |
KH-W100H2 |
KH-W101H2 |
KH-W131E2 |
KH-W201E2 |
KH-W202E2 |
|
Image Sensor |
1/4" CMOS |
1/4" CMOS LUX |
1/3" SONY LUX |
1/2.5" CMOS LUX |
1/2.5" SONY LUX |
|
Effective Pixels |
1.0 MP |
1.0 MP |
1.3 MP |
2.0 MP |
2.0 MP |
|
Image Resolution |
1280X720P |
1280X720P |
1280x960P |
1280X1080P |
1280X1080P |
|
IR LEDs |
24pcs Ø5mm IR LEDs |
||||
|
IR Distance |
25-30M |
||||
|
Lens |
3.6mm Lens, (6mm/8mm Optional) |
||||
|
Color |
Black/ White/ Grey Option |
||||
|
S/N Ratio |
>58dB |
||||
|
Shutter |
Auto/1/50(1/60)seconds to 1/100,000 seconds |
||||
|
WDR |
D-WDR |
||||
|
DNR |
2D-DNR/3D-DNR |
||||
|
Minimum illuminator |
0.01LUX/F1.2 |
0.001LUX/F1.2 |
|||
|
White Balance |
ATW/AWC-SET/Manual/AWB |
||||
|
AGC |
AUTO |
||||
|
BLC |
OFF/BLC/HSBLC |
||||
|
Transmission Distance |
Over 500m via 75-3 coaxial cable |
||||
|
synchronization System |
Internal Synchronization |
||||
|
Video Output |
AHD (1.0VP) |
||||
|
Voltage |
DC12V (9V ~ 15V) |
||||
|
Operating Environment |
-20°C~60°C / 10% ~ 95%RH ( AUTO Temperature Control Optional) |
||||
|
Dimension |
9.3x7.6cm |
||||
|
Weight |
0.38kg |
||||
